Nanopartz™ Custom Conjugated Gold Nanoparticles

Nanopartz™ Custom Conjugated Gold Nanoparticles includes the full line of monodisperse spherical, rod, microgold, and nanowire product familes for conjugation to customer specified ligands. We have extensive experience and inventory in conjugating the most popular covalent and charge based conjugations including Polyethylene Glycol (PEG), polystyrene, and more with the customer selected buffer. Upon conjugation, not only is every batch is completely purified, it is characterized including size, monodispersity, aggregation, residual chemicals, and concentration. A Certificate of Analysis (COA) is provided for every order exhibiting TEM and UV-VIS images and data, as well as DLS data. Customers have a choice of radiation sterilization and endotoxin postprocessing. This product is submitted for quotation through email. We normally respond within 1 hour. Products are normally ready for shipping within 24 hours of ordering. Prices start as low as $350.

Home » F- Customer Designed Nanoparticles
 Checkout
Conjugated Spherical Gold Nanoparticles for Research
Conjugated Spherical Gold Nanoparticles for Research
Part# AR11-(SIZE)-(LIGAND)-(TERM GROUP)-(OD-mLs) This product requires a quote. Please enter the following parameters and add to cart. Complete your contact information and submit for quote.
Sterilization
Certified Sterilized
Endotoxin
Endotoxin Purified
Endotoxin Purified and Certified
Price: $0.00
Conjugated Gold Nanorods for Research
Conjugated Gold Nanorods for Research
Part# AR12-(DIAM-SPR)-(LIGAND)-(TERM GROUP)-(OD-mLs) This product requires a quote. Please enter the following parameters and add to cart. Complete your contact information and submit for quote.
Sterilization
Certified Sterilized
Endotoxin
Endotoxin Purified
Endotoxin Purified and Certified
Price: $0.00
Conjugated Microgold for Research
Conjugated Microgold for Research
Part# AR13-(LENGTH)-(LIGAND)-(TERM GROUP); 0.25mg in 1mL Buffer. This product requires a quote. Please enter the following parameters and add to cart. Complete your contact information and submit for quote.
Sterilization
Certified Sterilized
Endotoxin
Endotoxin Purified
Endotoxin Purified and Certified
Price: $0.00
Conjugated Gold Nanowires for Research
Conjugated Gold Nanowires for Research
Part# AR14-(LENGTH)-(LIGAND)-(TERM GROUP); 0.25mg in 1mL Buffer; This product requires a quote. Please enter the following parameters and add to cart. Complete your contact information and submit for quote.
Sterilization
Certified Sterilized
Endotoxin
Endotoxin Purified
Endotoxin Purified and Certified
Price: $0.00









Part # Diameter (nm) Peak SPR Wavelength (nm) Optical Density (1cm) NPS/ml Wt. conc (mg/ml) Wt. % PPM Molarity (pM) Molar Ext. (M-1cm-1) Absorption Molar Ext. (M-1cm-1) Scattering Molar Ext. (M-1cm-1) Size Dispersity %PDI Notes
F11-1.8 1.8 505-508 50 4.25E+16 2.5 0.25% 2500 7.10E+07 7.05E+05 7.05E+05 0.00E+00 <35% 1,3
F11-2.2 2.2 505-508 50 2.33E+16 2.5 0.25% 2500 3.90E+07 1.29E+06 1.29E+06 0.00E+00 <25% 1,3
F11-3 3 505-508 50 9.19E+15 2.5 0.25% 2500 1.50E+07 3.26E+06 3.26E+06 0.00E+00 <20% 1,3
F11-4 4 505-508 50 3.88E+15 2.5 0.25% 2500 6.50E+06 7.74E+06 7.74E+06 0.00E+00 <20% 1,3
F11-5 5 505-508 50 1.99E+15 2.5 0.25% 2500 3.30E+06 1.51E+07 1.51E+07 0.00E+00 <20% 2,3
F11-10 10 514-520 50 2.48E+14 2.5 0.25% 2500 4.10E+05 1.21E+08 1.21E+08 0.00E+00 <15% 2,3
F11-15 15 514-520 50 7.35E+13 2.5 0.25% 2500 1.20E+05 4.08E+08 4.08E+08 0.00E+00 <15% 2,3
F11-20 20 514-520 50 3.10E+13 2.5 0.25% 2500 5.20E+04 9.67E+08 9.67E+08 0.00E+00 <10% 2,3
F11-25 25 514-520 50 1.59E+13 2.5 0.25% 2500 2.60E+04 1.89E+09 1.89E+09 0.00E+00 <10% 2
F11-30 30 523 50 9.19E+12 2.5 0.25% 2500 1.50E+04 3.26E+09 3.26E+09 0.00E+00 <6% 2
F11-35 35 526 50 5.79E+12 2.5 0.25% 2500 9.60E+03 5.18E+09 5.18E+09 0.00E+00 <6% 2
F11-40 40 527 50 3.88E+12 2.5 0.25% 2500 6.50E+03 7.74E+09 7.72E+09 2.24E+07 <4% 2
F11-45 45 529 50 2.72E+12 2.5 0.25% 2500 4.50E+03 1.10E+10 1.08E+10 2.03E+08 <4% 2
F11-50 50 531 50 1.99E+12 2.5 0.25% 2500 3.30E+03 1.51E+10 1.45E+10 5.88E+08 <4% 2
F11-55 55 533 50 1.49E+12 2.5 0.25% 2500 2.50E+03 2.01E+10 1.88E+10 1.30E+09 <4% 2
F11-60 60 536 50 1.15E+12 2.5 0.25% 2500 1.90E+03 2.61E+10 2.36E+10 2.48E+09 <4% 2
F11-65 65 539 50 9.04E+11 2.5 0.25% 2500 1.50E+03 3.32E+10 2.89E+10 4.33E+09 <4% 2
F11-70 70 542 50 7.23E+11 2.5 0.25% 2500 1.20E+03 4.15E+10 3.44E+10 7.09E+09 <4% 2
F11-75 75 545 50 5.88E+11 2.5 0.25% 2500 9.80E+02 5.10E+10 4.00E+10 1.10E+10 <4% 2
F11-80 80 549 50 4.85E+11 2.5 0.25% 2500 8.10E+02 6.19E+10 4.54E+10 1.65E+10 <4% 2
F11-85 85 553 50 4.04E+11 2.5 0.25% 2500 6.70E+02 7.42E+10 5.03E+10 2.39E+10 <4% 2
F11-90 90 558 50 3.40E+11 2.5 0.25% 2500 5.70E+02 8.81E+10 5.44E+10 3.37E+10 <4% 2
F11-95 95 563 50 2.89E+11 2.5 0.25% 2500 4.80E+02 1.04E+11 5.72E+10 4.65E+10 <4% 2
F11-100 100 569 50 2.48E+11 2.5 0.25% 2500 4.10E+02 1.21E+11 5.82E+10 6.27E+10 <4% 2
F11-125 125 600 50 1.27E+11 2.5 0.25% 2500 2.10E+02 2.36E+11 1.53E+11 8.32E+10 <4% 2
F11-150 150 612 50 7.35E+10 2.5 0.25% 2500 1.20E+02 4.08E+11 2.64E+11 1.44E+11 <4% 2



  Notes:
1
Size accuracy +/- 0.1 nm
1
Capping agent is covalently bonded carboxyl
2
Size accuracy +/- 2 nm
3
Peak SPR does not determine size for d<20 nm
Vol is 25mL, 100mL, 500mL, 1000mL
%PDI = Std Dev/Size
See Tech Note TN801 for definition of terms and method of analysis
All specs typical. May vary batch to batch. Exact values are measured for each batch
OD >=50 for all sizes
Shape monodispersity (% spheres) > 99.9%
Solution is 18MEG DI water
Residual Chemicals < 0.1%







Part # Diameter (nm) Length (nm) Peak SPR Wave (nm) Aspect Ratio OD SPR (AU) Peak LSPR Wave (nm) OD LSPR (AU) Nanorod Vol (nm3) Nanorods /mL Wt. conc (mg/ml) Wt. % PPM Molarity (nM) SPR Molar Ext. (M-1cm-1) LSPR Molar Ext. (M-1cm-1) Peak SPR accuracy (nm) SPR Linewidth 80% (nm)
F12-10-2100 10 175 2100 17.5 5 510 1 1.35E+04 6.73E+11 0.175 0.02% 175 1.12 4.46E+09 8.92E+08 1900-2300 300
F12-10-1400 10 102 1400 10.2 5 510 1 7.77E+03 1.17E+12 0.175 0.02% 175 1.95 2.57E+09 5.14E+08 1300-1500 150
F12-10-1200 10 81 1200 8.1 5 510 1 6.13E+03 1.48E+12 0.175 0.02% 175 2.47 2.03E+09 4.05E+08 1132-1300 150
F12-10-1064 10 67 1064 6.7 50 510 10 5.02E+03 1.81E+13 1.75 0.18% 1750 30.13 1.66E+09 3.32E+08 1022-1132 150
F12-10-980 10 59 980 5.9 50 510 10 4.33E+03 2.09E+13 1.75 0.18% 1750 34.91 1.43E+09 2.86E+08 965-1022 150
F12-10-950 10 55 950 5.5 50 510 10 4.09E+03 2.22E+13 1.75 0.18% 1750 37 1.35E+09 2.70E+08 925-965 150
F12-10-900 10 50 900 5 50 510 10 3.68E+03 2.47E+13 1.75 0.18% 1750 41.11 1.22E+09 2.43E+08 875-925 150
F12-10-850 10 45 850 4.5 50 510 10 3.27E+03 2.78E+13 1.75 0.18% 1750 46.25 1.08E+09 2.16E+08 829-875 100
F12-10-808 10 41 808 4.1 50 510 10 2.93E+03 3.10E+13 1.75 0.18% 1750 51.68 9.68E+08 1.94E+08 794-829 75
F12-10-780 10 38 780 3.8 50 510 10 2.70E+03 3.36E+13 1.75 0.18% 1750 56.06 8.92E+08 1.78E+08 765-794 65
F12-10-750 10 35 750 3.5 50 510 10 2.45E+03 3.70E+13 1.75 0.18% 1750 61.67 8.11E+08 1.62E+08 725-765 50
F12-10-700 10 29 700 2.9 50 510 10 2.04E+03 4.44E+13 1.75 0.18% 1750 74 6.76E+08 1.35E+08 675-725 40
F12-10-650 10 24 650 2.4 50 510 10 1.64E+03 5.55E+13 1.75 0.18% 1750 92.5 5.41E+08 1.08E+08 625-675 40
F12-10-600 10 19 600 1.9 50 510 10 1.23E+03 7.40E+13 1.75 0.18% 1750 123.34 4.05E+08 8.11E+07 575-625 40
F12-25-1400 25 245 1400 9.8 5 514 1 1.16E+05 1.12E+11 0.25 0.03% 250 0.19 2.69E+10 5.37E+09 1232-1500 150
F12-25-1064 25 137 1064 5.5 5 514 1 6.31E+04 2.05E+11 0.25 0.03% 250 0.34 1.46E+10 2.92E+09 1022-1232 150
F12-25-980 25 119 980 4.8 50 514 10 5.43E+04 2.39E+12 2.5 0.25% 2500 3.98 1.26E+10 2.51E+09 965-1022 150
F12-25-950 25 102 950 4.1 50 514 10 4.60E+04 2.82E+12 2.5 0.25% 2500 4.7 1.06E+10 2.13E+09 925-965 150
F12-25-900 25 96 900 3.8 50 514 10 4.30E+04 3.01E+12 2.5 0.25% 2500 5.02 9.95E+09 1.99E+09 875-925 150
F12-25-850 25 93 850 3.7 50 514 10 4.15E+04 3.12E+12 2.5 0.25% 2500 5.2 9.61E+09 1.92E+09 829-875 150
F12-25-808 25 90 808 3.6 50 514 10 4.01E+04 3.24E+12 2.5 0.25% 2500 5.39 9.27E+09 1.85E+09 794-829 150
F12-25-780 25 87 780 3.5 50 514 10 3.86E+04 3.36E+12 2.5 0.25% 2500 5.6 8.93E+09 1.79E+09 765-794 150
F12-25-750 25 85 750 3.4 50 514 10 3.76E+04 3.45E+12 2.5 0.25% 2500 5.75 8.70E+09 1.74E+09 725-765 65
F12-25-700 25 75 700 3 50 514 10 3.27E+04 3.96E+12 2.5 0.25% 2500 6.61 7.57E+09 1.51E+09 675-725 60
F12-25-650 25 71 650 2.8 50 514 10 3.07E+04 4.22E+12 2.5 0.25% 2500 7.03 7.11E+09 1.42E+09 625-675 60
F12-25-600 25 57 600 2.3 50 514 10 2.39E+04 5.43E+12 2.5 0.25% 2500 9.05 5.52E+09 1.10E+09 575-625 60
F12-25-550 25 34 550 1.4 50 514 10 1.28E+04 1.01E+13 2.5 0.25% 2500 16.91 2.96E+09 5.91E+08 525-575 60
F12-40-850 40 148 850 3.7 50 520 10 1.69E+05 7.67E+11 2.5 0.25% 2500 1.28 3.91E+10 7.83E+09 829-875 60
F12-40-808 40 134 808 3.4 50 520 10 1.52E+05 8.56E+11 2.5 0.25% 2500 1.43 3.51E+10 7.01E+09 794-829 60
F12-40-780 40 124 780 3.1 50 520 10 1.39E+05 9.33E+11 2.5 0.25% 2500 1.55 3.22E+10 6.43E+09 765-794 60
F12-40-750 40 112 750 2.8 50 520 10 1.24E+05 1.05E+12 2.5 0.25% 2500 1.74 2.87E+10 5.73E+09 725-765 60
F12-40-700 40 92 700 2.3 50 520 10 9.88E+04 1.31E+12 2.5 0.25% 2500 2.19 2.29E+10 4.57E+09 675-725 60
F12-40-650 40 80 650 2 50 520 10 8.37E+04 1.55E+12 2.5 0.25% 2500 2.58 1.94E+10 3.87E+09 625-675 60
F12-40-600 40 68 600 1.7 50 520 10 6.87E+04 1.89E+12 2.5 0.25% 2500 3.15 1.59E+10 3.18E+09 575-625 60
F12-40-550 40 60 550 1.5 50 520 10 5.86E+04 2.21E+12 2.5 0.25% 2500 3.69 1.36E+10 2.71E+09 525-575 60
F12-50-800 50 145 800 2.9 50 530 10 2.52E+05 5.15E+11 2.5 0.25% 2500 0.86 5.83E+10 1.17E+10 750-825 60
F12-50-700 50 110 700 2.2 50 530 10 1.83E+05 7.08E+11 2.5 0.25% 2500 1.18 4.24E+10 8.48E+09 650-750 60
F12-50-600 50 100 600 2 50 530 10 1.64E+05 7.93E+11 2.5 0.25% 2500 1.32 3.78E+10 7.57E+09 550-650 60







Part # Diameter (nm) Length (nm) Aspect Ratio Peak SPR Wave (nm) SPR OD (1cm) Microgold Vol (nm3) Microgold /mL Wt. conc (ug/ml) Wt. % PPM Molarity (pM) SPR Molar Ext. (M-1cm-1)
F13-500 75 500 6.7 510 0.25 2.10E+06 1.24E+09 50 0.01% 50 2.06 1.21E+08
F13-1000 100 1000 10 510 0.25 7.59E+06 3.42E+08 50 0.01% 50 0.57 4.39E+08









Part # Diameter (nm) Length (nm) Aspect Ratio Peak SPR Wave (nm) Nanowires Vol (nm3) Nanowires /mL Wt. conc (ug/ml) Wt. % PPM Molarity (pM) SPR Molar Ext. (M-1cm-1)
F14-1000 75 1000 13 510 4.31E+06 3.01E+09 250 0.03% 250 5.02 9.96E+06
F14-2000 75 2000 27 510 8.72E+06 1.49E+09 250 0.03% 250 2.48 2.02E+07
F14-4000 75 4000 53 510 1.76E+07 7.39E+08 250 0.03% 250 1.23 4.06E+07
F14-6000 75 6000 80 510 2.64E+07 4.91E+08 250 0.03% 250 0.82 6.10E+07
F14-10000 75 10000 133 510 4.40E+07 2.94E+08 250 0.03% 250 0.49 1.02E+08







Composition

These gold nanoparticles, nanorods, microgold and nanowires are shipped standard in microcentrifuge tubes.

Quantity

This product is available in 2.5mg and 5mg for the spheres, OD 50 and 250 for the nanorods and Plasmonic Fluorophores™ and 0.25mg for the microgold and nanowires. For larger orders, please contact sales for quantity pricing.

Introductory Kits

Unfortunately there are no kits available for this product at this time.

Delivery

All are in stock and ship fedex.

Conjugation

This is provided by the customer.

Shelf Life/Storage Temperature

This product is guaranteed for one year and may be stored at room temperature.

Toxicity

These products are non cytotoxic. The ligand may make them toxic.

Sterilization

This product is sterilized.

Certifications

This product is manufactured using our audited ISO 9000/2001 quality control system. Every order comes with a Certification of Analysis that includes the following information. We use NIST traceable:

UV-VIS (Agilent 8453) for extinction and concentration measurements

NIR (Cary 500) for NIR extinction and concentration measurements

DLS (Malvern Nano ZS) for zeta potential measurement

ICP-MS (Varian 820-MS) for gold mass measurements

TEM (Phillips CM-100 100KV) for sizing

These particles utilize Nanopartz™ expertise as world leaders in gold conjugation. Utilizing Nanopartz™ capabilities, customers now have the ability to have custom gold nanoparticles and conjugation made for research purposes. Customers detail the ligands wanted, and Nanopartz™ provide the resultant product completely characterized using NIST traceable TEM, UV VIS, DLS, HPLC, and ICP instrumentation. Most importantly, the customer will know the exact loading of the nanoparticles and will be given options for sterilization and for endotoxin free products.





  Nanopartz™ in vitro Gold Nanoparticles Citrate spherical gold nanoparticles with adsorbed conjugates
Stability (salt,pH,chemicals) High Low
Scattering linewidth Narrow (monodisperse) Broad (polydisperse)
Multilabeling Yes (500nm-2100nm) Limited (520nm-600nm)
Nonspecific binding Very low High
pH and salt resistance High Medium
Sterilization Radiation Sodium Azide
Site specific antibody conjugation Yes No





  • Stable
  • Well Characterized
  • Customer can select buffer
  • Customer can select gold nanoparticle type, size and/or SPR
  • Loading of all ligands is optimized
  • Low cost
  • Customer can focus on research and not on Nanopartz™ expertise
  • Customer will have all necessary data for publication
  • Quick turnaround

microgold in vitro

Custom Conjugated Gold Nanoparticles

Will you provide me the loading for the reactive groups for my journal paper?

Yes

Will you provide me a Certificate of Analysis containing all the necessary information for my journal paper?

Yes.

Will you disclose details on how you manufacture the product?

Unfortunately no.

Can I choose any buffer?

That depends on the requested conjugation, but in general, yes. We will advise if we don't think that a particular buffer is optimal for a particular product.

Can you help me put together procedures to use the product?

Absolutely.

Can you perform these conjugations and still keep the nanorod SPR where I specify?

Yes.

Can you work with very short covalent ligands, like 4 carbon lengths and have the particles stable?

Yes!

"We have looked at many different gold nanoparticles samples from Nanopartz including spheres, rods, and microrods using single particle spectroscopy techniques and are extremely happy with the quality of the samples and the service provided by Nanopartz."

Stephan Link, PhD
Assistant Professor of Chemistry
Rice University
